Air conditioning does not mean dust free atmosphere when you plan to protect your costly installations and equipments from airborne dust particles of sub-micron size.
As you are aware that air-conditioning filters can stop dust particles upto 20/30 microns only (1 micron = 1000th of mm), it becomes extremely difficult to create and maintain dust free atmosphere merely by window type Air-conditioner or centrally air conditioning system. Cecon Air Cleaners are the only perfect solution to improve the air quality in any specific area for maintaining dust free atmosphere without making any change in your existing infrastructure.
These COMPACT ELECTRONIC AIR CLEANERS are easy to install and are highly useful in places like Computer centres, Process Control rooms, Electronic Industries, Telephone Exchange, Research laboratories, Operation Theatres and many other places requiring clean and dust free atmosphere.
Cecon Air Cleaner works on the principle of Dust precipitation through high voltage. Contaminated/Dust Polluted air passes through charging cassettes of the equipment where dust particles as low as .01 to .03 micron regardless of being conductive or non-conductive are precipitated and collected on cassette plates in the dust collection unit of the equipment. Outgoing clean air is further passed through trap filtration barrier of Air Cleaner where it is once again filtered and neutralized of the charge. Thereby dust-free clean air is re-circulated in the room through inbuilt circulating system of the Air Cleaner.
⁕ Compact
⁕ Portable
⁕ Strong Laminated Body
⁕ Zero-Maintenance
⁕ Low Power Consumption
⁕ Computer room
⁕ Operation theatre
⁕ Cement industry
⁕ Steel plant
⁕ Control room
⁕ Tissue-culture lab
⁕ Thermal power station
⁕ Electronic industry
Cecon Air Cleaner is built with integral fan/motor assembly and precipitator unit with high precision electronic controls and solid state power supply system having built-in short circuit protection fitted with electronically controlled line voltage stabilizer to work on 220 volts single phase. The unit has very low power consumption of 150 watts. Portable and compact Cecon Air Cleaner has strong laminated metallic body construction fitted with castor rolls for easy mobility. The dust collection unit can be cleaned conveniently and has nil maintenance cost with no replacement of filtration unit or other component. The unit can be placed at any corner of the room/hall for silent trouble free performance.
Modal | Capacity | Room Size | Weight |
ADC-2000 | 6000 cfm | 60' x 10' x 10' | 80 kg |
ADC-900 | 3000 cfm | 30' x 10' x 10' | 45 kg |
ADC-850 | 2500 cfm | 25' x 10' x 10' | 40 kg |
ADC-400 | 1500 cfm | 15' x 10' x 10' | 35 kg |
Universal Model | 1200 cfm | 12' x 10' x 10' | 25 kg |
Note: Higher capacity models are available on request. |
